Graphics Engine

 AMD Radeon™ RX 9060 XT

Bus Standard

PCI^® Express5.0 x16

DirectX

12 Ultimate

OpenGL

4.6

Memory

GDDR6 16GB

Engine Clock

Boost Clock*: Up to 3320 MHz
Game Clock**: 2780 MHz

*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

2048

Memory Clock

20 Gbps

Memory Interface

128-bit

Resolution

Digital Max Resolution: 7680×4320

Interface

2 x DisplayPort 2.1a
1 x HDMI 2.1b

HDCP

Yes

Multi-view

3

Recommended PSU

550W

Power Connector

1 x 8-pin

Accessories

1 x Quick Installation Guide

Dimensions

298 x 131 x 51 mm, 2.55-slot

Net Weight

967 g
