General Specifications

Platform

Boxed Processor

Product Family

AMD Athlon™ Processors

Product Line

AMD Athlon™ Desktop Processors with Radeon™ Graphics

Former Codename

“Picasso”

# of CPU Cores

2

# of Threads

4

Base Clock

3.5GHz

L1 Cache

192KB

L2 Cache

1MB

L3 Cache

4MB

Default TDP

35W

Processor Technology for CPU Cores

14nm

Unlocked for Overclocking

Yes

CPU Socket

AM4

Max. Operating Temperature (Tjmax)

95°C

*OS Support

Windows 11 – 64-Bit Edition

Windows 10 – 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

Connectivity

PCI Express® Version

PCIe® 3.0

Memory Channels

2

System Memory Specification

Up to 2667MHz

Graphics Capabilities

Integrated Graphics

Yes

Graphics Model

Radeon™ Vega 3 Graphics

Graphics Core Count

3

Graphics Frequency

1100 MHz
