Form Factor

ATX

Watts

600W

PFC

Active PFC

Input Frequency

50-60Hz

ErP 2014 Lot 3

Yes

Operating Temperature

0-40°C

ATX 24 Pin Connectors

1

EPS 4+4 Pin Connectors

1

Power Good Signal

100 – 500 ms

MTBF

>100,000 Hours

Fan Size

120mm

Category

500 to 750W

Modular

Non Modular

Input Current

4A

Fan Bearing

Sleeve Fan

80 Plus

None 80 PLUS

PCI-e 6+2 Pin Connectors

2

Peripheral 4 Pin Connectors

3

Protections

OVP, OPP, SCP, UVP, OTP, Inrush Protection

SATA Connectors

5

ATX Version

ATX 12V Ver. 2.41

Input Voltage

200-240V

Dimensions (L x W x H)

140 x 150 x 86 mm

Regulatory

CCC, CE, EAC, TUV, UKCA

Series

Elite Series

Hold Up Time

≥10ms at 100% load

Efficiency

≥ 75% @ Typical Load

Model

MPW-6001-ACBK-P
